Transmission Towers
Angle and tubular tower modeling.
3D Modeling
Accurate Modeling. Better Visualization. Smarter Decisions.
Intelligent 3D models transform design concepts into coordinated geometry, fabrication details and reliable quantity information.
High AccuracyBetter CoordinationCost EfficiencyReliable Output
High AccuracyExact representation
Better CoordinationResolve conflicts early
Cost EfficiencyReduce rework
Reliable OutputModels, drawings and BOQ
3D Modeling Capabilities
Detailed models support transmission, substation, pole and foundation projects.
Substation Structures
Steel structures and equipment supports.
Steel Poles & Crossarms
Tapered poles, flanges and accessories.
Foundations & Anchor Bolts
Coordinated structural interfaces.
Connection Detailing
Bolts, plates and member connections.
Clash Detection
Identify conflicts before fabrication.
Quantity Take-off
Accurate material lists and BOQ.
Multi-format Output
IFC, STEP, DWG, PDF and Excel.
3D Modeling Workflow
A transparent, review-driven process from project input to final delivery.
01Project Input2D drawings and requirements
02Model PreparationCoordinates and modeling rules
033D ModelingDetailed components and connections
04Review & CheckClash and quality verification
05DeliverablesModels, drawings and BOQ
Detailed Deliverables
- 3D BIM model (Tekla / CAD)
- General arrangement drawings
- Connection and node drawings
- Foundation layout drawings
- Material take-off and BOQ
- Fabrication and erection drawings
Modeling Highlights
- Accurate connections
- Overall structure coordination
- Foundation integration
- Clash detection
- Fabrication-ready output
- Multi-format handover
LOD 300–400Model Detail
HighGeometry Accuracy
CompleteQuantity Take-off
EarlyClash Resolution
Standards & Software
Tekla StructuresSAP2000ETABSAutoCADPLS-CADDSketchUp
Accurate Modeling. Better Visualization. Smarter Decisions.
Share your project requirements with our engineering and sales team.
